For gas:natural gas;liquefied petroleum gas;artificial gas and other non-corrosive gases
Drive voltage:DC9V~DC12V(Pulse)
Valve Material:Brass Alloy
Drive current:<1.5A(Pluse)
Sealing Material:NBR rubber
Off valve time:less than 1 second
Working environment temperature:-10۫C~+50۫C
Explosion-proof type:poured seal-type
Maximum working pressure:25kPa
Outlet length:0.4meters
Connection:G1/2"(DN15A)G3/4"(DN20A)
The way Off valve:DC pulse drive/Manual
The way Open valve:Manual Reset
|
