Size: DN50-DN900
Valve Body: Cast iron/ Ductile iron/Stainless steel
Knife: SS304/SS316/SS2205
Stem: SS420/SS304/SS316
Seat Types: EPDM/NBR/Vilton/PTFE/Metal to Metal
Connection Available: EN, API, JIS, DIN (PN10, PN16, 150LB, 10K, Table E/D)
Working Pressure:
DN50~DN250:10Bar
DN300~DN450:7Bar
DN500~DN600:4Bar
DN700-DN900:2Bar
Operator: Hand wheel, Bevel Gear, Chain wheel, Electric Actuator, Pneumatic Actuator
Application：
For fluid and powder medium:
Water treatment
Potable water, waste water
Chemical industry
Pulp industry
Other inert fluids
