8HY
SeriesMode/StepAngle/MotorLength/RatedCurrent/HoldingTorque /lead Wire
degree mm A N.cm Min
20BYGH2402 1.8 28 0.2 1.4 4
20BYGH2406 1.8 28 0.6 1.4 4
20BYGH3402 1.8 34 0.2 1.8 4
20BYGH3406 1.8 34 0.6 1.8 4
20BYGH4402 1.8 40 0.2 2.6 4
20BYGH4406 1.8 40 0.6 2.6 4
|
