● Working temperature: -20-60℃
● Supply voltage: DC5V, 12V，18V, 24V < optional > ( supply voltage should be marked on order )
● Output: 1 channel
● Connection mode: common anode
● External dimension: L86 Χ W86 Χ H36 mm
● Packing size: L140 Χ W50 Χ H60 mm
● Net weight: 125g
● Gross weight: 150g
● Static power: <1W
● Output current: <4A (each channel)
● Output power: 5V<45W, 12V<108W, 24V<216W
|
